Description
Quantified vertical blast/safety bolt design, ensures samples be closed completely and trigger a quantified pressure relief while over pressure; safety bolt (patent) unit, instead of safety membrane and other consumables, ensure the digestion vessel be sealed completely under normal working conditions. And only when the pressure is large enough and may constitute a danger to the safety, the safety bolt will automatically blow out vertically and the cover auto-up to release the pressure, achieving quantified vertical blast pressure-relief to guarantee its well operation. Under normal operation, the safety bolt won’t blow out and requires no replacement. In addition, it is easy for venting to open the cover after completion of digestion.
The industrial-leading pressure measuring technology by piezoelectric crystal and high-precision Pt sensor temperature measurement and control, through closed-loop control of microwave power by inverter technique, ensure the accuracy of pressure and temperature monitoring and control. The application of patented piezoelectric crystal brings about complete isolation of samples from pressure measurement system in digestion process, thoroughly solving the problems of cross contamination of samples due to commonly used air pipe in market and of the limitation in digestion samples because of low-pressure proof of air pipe.
Automatic Frequency Control of Non-pulse Microwave Power ensures the accurate closed-loop control of the temperature and pressure, and also improves the efficiency of microwave transmitter of magnetron. 12 vessel per bath throughput capability, increase the efficiency of the pretreatment in the lab.
The patented design that the whole set of digestion vessels in chamber always continuous rotates in one direction, breaks conventions of<360° back and forth rotation of the digestion unit, avoiding uneven heating on vessels by microwave and reducing impact on turntable motor, extending service life.
The new digestion, changing its traditional bulky appearance, uses European industrial design, colorful and smart, that in line with the needs of modern laboratory building. It re-layout its internal structure more scientifically that it reduces the volume of the machine while providing 42L reactor chamber to ensure uniform heating of the microwave and convenient operation.
Sturdy and durable industrial-grade chamber design strengthen its impact resistance; Professional focused microwave design make microwave heating more efficient; Multi-layer chemical resistant coating greatly improves the service life and safety of the system; the popup cushioning explosion-proof sliding chamber door builds a passive safety protection system, easing operation; double-locked self-checking system of the chamber door and the push-type open-door mechanism at the top make the operation simple and easy; efficient exhaust system design achieves fast and safe air-cooled cooling (20 min cooling from 200℃ to 60℃), improving operational efficiency.
Jupiter series have many advantages: safety external PC control; friendly windows interface that is easy to be operated; display digestion temperature, pressure and changes of microwave transmit power in real time; directly display its working process; through computer’s remote control station, do operations such as setting, running, change time and power etc.; the software can save unlimited amount of digestion solution, making it convenient for users; the user-friendly software operation like a chemist, who help you complete various operations, providing customers with safe, scientific and convenient operation experience (color software and computer connection are for Jupiter-A).
